Products are categorized into two types: those displaying measurements in millimeters only.
Model
Categories : Measuring Tools , Micrometer , MEASURING TOOLS , Measuring Tools , Micrometer ,
Brand : MITUTOYO
Share
Product Descrptions
| Order No. | Range (mm) | Graduation (mm) | Maximum permissible error JMPE (μm) | Remarks |
|---|---|---|---|---|
| 147-103 | 0-13 | 0.01 | ±3 | - |
| 147-105 | 0-13 | 0.01 | ±3 | for aluminum cans. |
| 147-202 | 0-13 | 0.01 | ±3 | for spray cans. |
Specification ( Model Unit : Inch )
| Order No. | Range (in) | Graduation (in) | Maximum permissible error JMPE (in) | Remarks |
|---|---|---|---|---|
| 147-104 | 0-0.5 | 0.001 | ±0.00015 | - |
| 147-106 | 0-0.5 | 0.001 | ±0.00015 | for aluminum cans. |
| 147-201 | 0-0.5 | 0.001 | ±0.00015 | for spray cans. |
Measurement example
![Mitutoyo Micrometer No.147-103 [3]](https://image.makewebeasy.net/makeweb/r_60x60/jIt9pLLeM/mitutoyoOpic/Mitutoyo_Can_Seam_Micrometer_Series_147_103_[2_.jpg?v=202405291424 "Mitutoyo Micrometer No.147-103 [3]")
![Mitutoyo Micrometer No.147-103 [2]](https://image.makewebeasy.net/makeweb/r_60x60/jIt9pLLeM/mitutoyoOpic/Mitutoyo_Can_Seam_Micrometer_Series_147_103.jpg?v=202405291424 "Mitutoyo Micrometer No.147-103 [2]")
